    JAC J5P 6x4 20-30 ton construction work heavy duty dumper truck

    Ask Lasest Price
    Brand Name : JAC
    Certification : CCC,ISO
    Price : USD38,500.00-USD40,000.00 per unit
    Payment Terms : 30%TT as deposit, the balance should be paid before delivery; 100% irrevocable confirmed L/C at sight
    Supply Ability : 3000units/month
    Delivery Time : 30-45 days
    • Product Details
    • Company Profile

    JAC J5P 6x4 20-30 ton construction work heavy duty dumper truck

    JAC J5P 6x4 20-30 ton construction work heavy duty dumper truck


    1,high-duty steel:main beam,side beam and key parts use domestic advanced technology standardlow-alloy and high-strengthsteel.
    2,low consumption:light weight cut down fuel use and save transportation cost.
    3,high return:reduce self-weight,increace customer's transportation profit.
    Products Technical Specification
    TypeJAC 6*4 Dump Truck
    CabHalf row,single sleeper,with A/C
    Vehicle Description
    Overall dimensions(mm)7835*2495*3500
    G.V.W (kg)25000
    Curb weight(vehicle) (kg)11800
    Loading capacity (kg)20000-30000
    Max speed (Km/h)80
    Engine
    Engine modleWP10.300E40
    Maximum power221kw (300hp)
    Displacement (lit)9.726
    Engine ManufacturerWeichai power Co., Ltd.
    Chassis Description
    Chassis modelHFC3241
    Wheel base3490+1350
    F/R track base(mm)2057/1880
    F/R overhang(mm)1495/1500
    Approach/Departure angle(°)27/26
    Spring plate10/12
    Front axle / rear axleSteyr
    Type of fuelDiesel
    Fuel of capacity350 L
    Gear boxFAST , 10-speed with over drive
    Electric system24V
    Tyres11.00R20
    Dumper body Description
    Van dimensions(mm)5200*2300*1500 /1800
    Van descriptionEquipped with material of carbon steel,
    side 6mm thickness; bottom 8mm thickness
    with middle / front lifting system
    Optional EquipmentTires,Dumper body thickness,middle hydraulic ram,
    side door,etc

    Dump truck

    tipper truck

    Dumper truck
